Quattro-II 24/3000/70-50/50 2x120V
$1,813.10
-
PowerControl and PowerAssist – Enhances the grid or generator capacity by managing energy usage and preventing overloads.
-
Two AC Inputs and Two AC Outputs – Allows connection to multiple power sources with efficient distribution of power.
-
Virtually Unlimited Power with Parallel and Three-Phase Operation – Scalable power output for larger systems, providing flexibility and high capacity.
-
On-Site System Configuring, Monitoring, and Control – Easy local management and adjustments of the system setup.
-
Remote Configuring and Monitoring – Full remote control and monitoring through internet connectivity for convenience and accessibility.
Flexible Power with the Victron Energy Quattro-II 24/3000/70-50/50 2x120V
The Victron Energy Quattro-II 24/3000/70-50/50 2x120V is a versatile inverter/charger designed for standard North American 50A 120/240VAC split-phase applications. It seamlessly manages two AC inputs, automatically connecting to the active source, whether from shore power or a generator.
The Quattro-II accepts and transmits both lines of a 120/240V supply, using the full 50A for both charging and AC loads. In single-phase 120V mode, the L1 input powers charging and passthrough while combining L1 and L2 outputs to deliver 120V on each line. When no AC sources are available, the Quattro-II switches to inverter mode, providing 120V single-phase output by internally linking L1 and L2.
Equipped with features like PowerControl, PowerAssist, Input Current Limit, and compatibility with parallel and 3-phase configurations, the Quattro-II 2x120V is compatible with LiFePO4 and other battery technologies. It also supports expanded power through parallel operation (up to 6 units) or three-phase output (using 3 units).
Product Specs
Product Manual
| Dimensions | 13 × 23 in |
|---|
